Large-screen technology is at the heart of modern control centers – and for us, it is much more than just a wall of monitors! For almost 30 years, we have been developing visualisation concepts that make complex processes transparent and provide all parties involved with information in real time. Whether precisely coordinated LCD walls, scalable LED solutions or individually combined systems: finding the right platform for every task is one of our priorities when planning control rooms. We make information visible where it is needed. Maximum 24/7 operational reliability and uncompromising image quality are just as important as ergonomic viewing conditions and flexible scalability in the event of growing requirements.
DisplayWall technology from JST ensures reliable signal management on the video wall. Alarms, camera images and process data are clearly displayed. With features such as automated event visualisation, proactive alarm escalation and flexible source control, we create the conditions for clear responsibilities and short response times. This allows operators to act confidently even under time pressure!
What video and display walls must deliver in the control room
Just large images? Merely a central visualisation of process control systems? Modern large-screen technology must be capable of more! Ideally, the technology should create a genuine extension of the workplace. For example, the operator uses the large-screen system to analyse or discuss details with colleagues. However, event-driven alerts for the entire team are also important – a step towards improved operational safety.
Large-screen systems in 24/7 operation must function reliably. Basis: fail-safe technology, redundant power supplies and long operating times without loss of brightness.
High resolution, uniform brightness and a wide viewing angle are crucial. This ensures that all information can be quickly captured, even in changing light conditions.
Whether process data, video streams or alarms – content needs to be placed dynamically on the video wall at any time. The right KVM solution makes it happen.
In an emergency, every second counts in the control room. Tools like the PixelDetection® video wall alarm software ensure that critical events are displayed automatically.
If the control room grows, the video wall must also be expanded. To make it easy to integrate additional displays later on, a modular design should be considered.
In addition to technology, impact also plays a role. Glare-free surfaces, discreet frames and intuitively organised display layouts convey professionalism and facilitate operation.
Event visualisation in the control room: intelligent video wall becomes a proactive colleague
One glance at the video wall – and you immediately know what needs to be done. Those who maintain an overview in control rooms and monitoring stations also have critical processes under control. Modern large-screen technology is becoming the visual backbone of control rooms. It ensures that operators can reliably access all information, even under time pressure. Investing in high-resolution displays, sophisticated control concepts and proactive alarm visualisation today gives your team a decisive advantage – both in daily routine and in emergencies.
Control room expert Dominik Zepp knows exactly: time-critical decisions have to be made continuously in the control center. Large-screen technology not only gives the operator an improved overview and thus added safety. In addition, positive effects can be recorded on the credit side thanks to ‘TeamView’. The entire control room team receives identical information, status and alarm messages at the same time.
Modern video wall technology offers decisive benefits – we talk to a specialist in large-screen visualisation: Dominik Zepp from JST – Jungmann Systemtechnik® explains which factors should be considered when choosing the right system and which benefits can already be achieved today by combining it with smart control and software solutions.
Why do control rooms use video walls with large-format displays in addition to the monitors at the operator workstation?
Dominik Zepp: Large-screen technology is more than just a desirable nice-to-have in the control room. It has a very central role to play: safety-related information is continuously visible to the entire team in real time. Camera images, process data or alarm messages can be displayed in high resolution on a video wall. This not only provides the desired overview, but also transparency and reliability – especially when several operators are working in parallel.
What advantages do modern video walls offer? Are they also suitable for continuous operation?
Dominik Zepp: The screens we recommend to our customers for their control rooms are based on LCD and LED technologies that have been specially developed for the business sector and differ significantly from conventional monitors. The displays must be extremely durable. Our systems are designed for 24/7 use and offer stable brightness, consistent colour fidelity and a particularly long service life. They are also designed to minimise maintenance cycles and reduce downtime to a minimum. These advantages are indispensable for safety-critical applications.
Is it possible to seamlessly integrate large-screen technology into existing IT structures at a later date?
Dominik Zepp: JST systems are modular in design and can be combined flexibly. Thanks to our KVM solutions JST MultiStreaming® and MultiConsoling® in combination with the myGUI® operating platform, content can be controlled, moved and prioritised as required, regardless of the manufacturer. This means that whether it’s a video stream, process visualisation or alarm display, everything can be switched on exactly where it’s needed.
On-site appointments and intensive coordination with project managers are among the key prerequisites for successful control room implementation, according to JST consultant Dominik Zepp. His goal is to deliver highly professional and future-proof solutions that combine large-screen technology, operating concepts and ergonomic workstations. The control center professional focuses on components that harmonise perfectly with each other and function flawlessly with high availability.
On-site appointments and intensive coordination with project managers are among the key prerequisites for successful control room implementation, according to JST consultant Dominik Zepp. His goal is to deliver highly professional and future-proof solutions that combine large-screen technology, operating concepts and ergonomic workstations. The control center professional focuses on components that harmonise perfectly with each other and function flawlessly with high availability.
On-site appointments and intensive coordination with project managers are among the key prerequisites for successful control room implementation, according to JST consultant Dominik Zepp. His goal is to deliver highly professional and future-proof solutions that combine large-screen technology, operating concepts and ergonomic workstations. The control center professional focuses on components that harmonise perfectly with each other and function flawlessly with high availability.
On-site appointments and intensive coordination with project managers are among the key prerequisites for successful control room implementation, according to JST consultant Dominik Zepp. His goal is to deliver highly professional and future-proof solutions that combine large-screen technology, operating concepts and ergonomic workstations. The control center professional focuses on components that harmonise perfectly with each other and function flawlessly with high availability.
DOMINIK ZEPP:
“We are just at the beginning: large-screen technology will merge even more closely with automation, AI and interaction in the coming years. What provides an overview today will think proactively tomorrow – and thus fundamentally change the way we work in the control room.”
Can the alarm visualisation on the video wall be automated?
Dominik Zepp: Yes, absolutely. With our PixelDetection® alarm software, you can set it up so that defined events are automatically displayed on the video wall. The monitoring tool even checks the screen content that is not currently visible in the background. Let’s assume that a predefined parameter is exceeded or not reached within a process. The operator then receives a warning message and the affected area is immediately visualised. This allows the control room team to take action before a deviation potentially escalates into a serious alarm. This saves valuable seconds and ensures that the operator team does not miss any critical information.
What sizes and video wall variants are available for different control room concepts?
Dominik Zepp: We always plan large screens on an individual basis. The spectrum ranges from compact solutions with individual modules to room-filling installations consisting of dozens of displays. The size depends on many factors: room dimensions, viewing distances, desired information density and, last but not least, the operating concept. Together with the customer, we develop a setup that fits perfectly into the overall architecture.
What role does ergonomics play in large-screen visualisation?
Dominik Zepp: Ergonomics is often underestimated. But the placement of displays, viewing angles and brightness adjustment are crucial in determining whether information can be absorbed quickly enough. That’s what it’s all about: can the operator actually process the data provided in the shortest possible time? Do they react at the desired speed? To answer these questions with a ‘yes’, the equipment must be perfectly coordinated. We attach great importance to ensuring that sight lines are calculated correctly, contrast values are appropriate and lighting conditions are taken into account. Ultimately, these factors increase the ability to concentrate and reduce stress during long shifts.
LCD or LED – which large-screen technology is suitable for my control room?
Dominik Zepp: That depends greatly on the specific conditions. LCD video walls offer excellent value for money, high-quality image display and a slim design. They are ideal when high resolution, clear contrasts and a compact design are required. LED technology, on the other hand, offers particular advantages for large viewing distances and extremely variable formats. Thanks to their modular design, LED walls can be scaled to almost any size and also score points for their excellent brightness and high colour stability over many years. We always advise our customers individually on which technology is best suited to the size of the room, the intended use and the budget. Even hybrid concepts are possible: for example, LED walls as the central display and LCDs for detailed information.
Where is large-screen technology heading in the next few years?
Dominik Zepp: We are observing two major trends: On the one hand, resolutions and colour brilliance continue to increase. On the other hand, the degree of automation is growing. Keyword: content management. In the future, systems will be increasingly able to intelligently prioritise content and display it automatically depending on events. In addition, the integration of touch interactions or augmented reality elements will open up new application scenarios.
Your workshop experience: Try out our visualisation solutions!
What fits better into your control room concept? LCD or LED technology? In our control room simulator, you can try out both solutions live on site. In this unique room of the future, everything revolves around ergonomics, process visualisation and operating concepts.
Take advantage of the free workshop in the control center showroom as a practical planning aid and lay the foundation for future-proof investment decisions, either live or in a virtual meeting.
The control station you can touch – live event in JST’s control room simulator
Take a look at our projects! Many options, one goal: how to visualise your processes in the control room
It is the hub where all information converges. A true team player when it comes to providing crucial information to all employees in the control room: the video wall offers visual support for monitoring in the control center, makes even complicated processes visible and opens up the option of securing decisions within the group. With our large-screen solutions, we anticipate the requirements of the digital future. This includes not only the professional planning and configuration of individually tailored visualisation technology, but also its implementation and calibration by our specialists. Over the past three decades, we have equipped hundreds of control rooms with state-of-the-art display technology. Take a look at our photo gallery to get a first impression of what it means to work with the leading control room specialists.
We offer our customers unique products and solutions for control rooms. An exclusive benefit that only JST can provide.
We have been working in the business for more than 30 years. We would be happy to bring our many years of know-how to your project.
This means that you benefit from our extensive experience and smooth project realisation processes. Because JST keeps everything in mind!
Our experts are among the best. They have been designing control rooms for years. Our team enjoys working together – for you!
All from a single source: KVM, furniture and visualisation
Security requirements and data volumes are growing. The pace of processing and visualisation is accelerating. Employees have to keep an eye on more and more sources at the same time – whether in the IT control center, in production, in alarm centers or in operations control rooms. To maintain an overview of the multitude of information sources, JST uses comprehensive turnkey solutions that effectively prevent overload.
Concentration and ease of use in the workplace are key issues here. Ergonomic control room furniture is just as much a part of the JST portfolio as innovative monitor walls, which proactively visualise alarms using intelligent software solutions. State-of-the-art KVM systems enable complex scenarios to be monitored and controlled – simply, quickly and securely.
„Ready to use“ – JST thinks of everything!
„Ready to use“ – JST thinks of everything!
Fixed contact person for all phases of the project
Workflow and task coordination with the specialist departments
Professional implementation of all components
Employee training and initialization of the new Control Center
Turnkey Solutions:
Integrated overall solution creates a real competitive advantage
You want a control center where all information comes together? A control room as a secure basis for the requirements of the digital future, precisely tailored to your processes and needs?
With our experience from more than 600 projects, we are the right partner for turnkey solutions that transform your control room into a profit center.
