Monitor walls and display walls with seamless 24/7 LC displays and alarm function

JST DisplayWalls are the big players in your control room. They are event-controlled, this means that computers and cameras can be automatically switched on and operated in real time without the operator having to intervene. The operator refers to this as “TeamView” because now the entire team has the same level of knowledge about the most important alarms.

REQUEST A QUOTATION
Ingo Müller - Helmholtz Center Berlin

Watch the video: New control center for science – Interview with Ingo Müller (Helmholtz-Zentrum Berlin)

JST DisplayWalls: Important advantages and possible designs

Quality: Designed for 24/7 operation in control rooms

Proactive:  Interfaces for event-controlled alarming with PixelDetection®

Well laid out:  Identifying causes and making decisions through “TeamView”

Operation: In real-time with keyboard & mouse, directly on the monitor wall

Event control: Computers and cameras are connected fully automatically in case of alarms

Six good reasons to choose JST DisplayWalls:

A DisplayWall consists of several large LC displays or rear-projection cubes that are installed on top of each other and side by side. This creates a large and coherent image.

01

Detailed representation

Relationships between different alarms are quickly and clearly recognized due to the large display area, large vertical and horizontal viewing angle, perfect illumination by energy-saving LED backlight and high pixel resolution.

02

Longevity

JST DisplayWalls are specially designed for 24/7 continuous operation in control rooms. These are explicitly not televisions that are used in the private sector.

03

Fast cause and decision finding through “TeamView

The entire control room team receives the most important information simultaneously. TeamView can even be operated simultaneously or alternately and in real-time directly on the DisplayWall. It becomes a real extension of the workstation desktop. Faster reaction and interference suppression through noticeably improved teamwork.

JST - InfraLeuna-Large screen wall with practical QuickOut system

Example: DisplayCover with QuickOut mounting system and AlarmLight in the InfraLeuna central control room

JST Large screen wall paneling: In the InfraLeuna central control room, the cladding of the large screen wall – here equipped with eight 46-inch displays with extra-slim frames – not only reduces the noise level in the control room but also offers additional storage space thanks to the multifunctional equipment with hinged doors.

Perfect service accessibility – even for displays located in the middle of a video wall – the JST QuickOut mounting system. By slightly pressing the outer edges of the display, each individual display slides forward (quick-out) to provide access to rear connections and technical components in case of inspection.

04

Clear, structured, tidy

By combining the most varied system, plant and hazard states, more efficient monitoring and control is made possible. There is no need for many workstation monitors. The operator always keeps the overview.

05

JST DisplayWalls have interfaces for event-controlled alarming!

This means: Display of the most important alarms, at the required time, at the right place and in the optimal size. Only in this way does the DisplayWall become a secure information hub where no alarm remains undetected.

06

More decision safety

In order to be able to act even faster and always in a coordinated manner, additional information is added to the alarms automatically and depending on the situation. A correlation of different alarms is also possible in a variety of ways. Only JST offers this special intelligence.
